Two families. One project desk in Bogotá.
eFillix machines from C.I. Steel, plus Kombi Makina complete beverage lines
This page is a general overview. eFillix / eSlim fillers are built in Bogotá and listed in Spanish on Envasadoras.co. Kombi Makina lines are designed in Istanbul; eFillix is the distributor for Colombia, the United States and Latin America. Ask for a quote with your product, bottle and bottles per hour.
eFillix / eSlim — made in Bogotá
Direct manufacturing at C.I. Steel. Overflow and volumetric fillers in 304 food-grade stainless for beverages, oils, liquors, detergents, chemicals, food, cosmetics and pharma.
Overflow 4, 6, 9 and 12 nozzles — semi-auto or automatic conveyor- Vertical volumetric 1-nozzle, optional electric thermal hopper
- Custom nozzles, tanks and speeds. FAT at the Bogotá plant.
Envasadoras.co
Kombi Makina — complete lines from Istanbul
Since 2003 Kombi designs, supplies, commissions and supports beverage filling machines and turnkey plants. More than 1,000 customers in more than 25 countries. CE certified.
- Water, juice, dairy, CSD and edible-oil filling lines
- PET blow, rinse-fill-cap, labeling, coding, packing, palletizing
- Capacities from a few hundred to 30,000 bottles per hour
kombimakina.com
eSlim Overflow
Overflow fillers for thin liquids
Overflow (level-fill) machines keep a consistent fill height in transparent bottles. The Bogotá catalog covers beverages, oils, liquors and chemicals. Frames and tanks are 304 stainless. Pumps can be centrifugal, pneumatic or gravity. Conveyors use acetal chain, 110 V or 220 V, with plant air typically 7–9 cfm.
- Semi-automatic 4-nozzle and automatic 4 / 6 / 9 / 12-nozzle frames
- Typical range 100 ml – 4,000 ml (12-nozzle up to 5,000 ml)
- Indicative speed: about 8–24 bottles per minute depending on nozzles and viscosity
Typical overflow configurations
General ranges from the Envasadoras.co factory catalog. Final speed depends on bottle and product.
| 4 nozzles, automatic | ~8–12 bottles/min · 100–4,000 ml · ~150 cm conveyor |
|---|---|
| 6 nozzles, automatic | ~12–15 bottles/min · 100–4,000 ml · ~250 cm conveyor |
| 9 nozzles (e3) | Higher-output overflow frame for thin liquids |
| 12 nozzles, automatic | ~12–24 bottles/min · 100–5,000 ml · ~300 cm conveyor |
eSlim Volumétrica
Volumetric fillers for viscous products
Vertical volumetric machines dose a set volume — useful for liquids, semi-viscous, viscous and paste products in food, chemical and cosmetic plants. The standard 1-nozzle unit uses a ~22 L 304 tank (gauge 14), 110 V, and plant air around 100 PSI. Cylinder ranges typically cover 10–100 ml, 50–500 ml, 100–1,000 ml and ¼ gal–1 gal.
- Optional electric thermal hopper for products that must stay warm
- Compact bench footprint, factory warranty and spare parts from C.I. Steel
- Cappers and labelers can be added around the filler for a small line
How we specify an eFillix machine
| Product | Viscosity, foam, temperature, particles |
|---|---|
| Container | Volume, neck, PET / glass / HDPE |
| Speed | Bottles per minute or per hour |
| Utilities | 110 / 220 V, compressed air, drain |
| Acceptance | FAT in Bogotá, bilingual manuals, spare parts |
Kombi Makina
Turnkey beverage filling lines
Kombi filling machines rinse, fill and cap PET, HDPE or glass. Electronic flowmeters give volumetric control; gravity fillers handle other bottle formats. Cappers cover chuck, snap and spindle closures. A complete line can add PET blow molding, water treatment, blending, deaeration, pasteurizing, hot-fill and cooling (juice), labeling, date coding, shrink or carton packing and palletizing.
Water filling lines
Hygienic still-water plants with PET blow, filler-capper, labeling, coding, packing, palletizing and water treatment. Built to cut waste and keep the line efficient.
| PET 200 ml – 2 L | 2,000 – 30,000 bph |
|---|---|
| PET 3 L – 12 L | 600 – 3,000 bph |
| PET 5 L – 19 L | 350 – 700 bph |
| PC 19 L (5 gal) | 200 – 2,200 bph |
Juice filling lines
Sanitary handling of pulp, concentrates and additives. Typical line: blending tanks, deaerators, pasteurizers, mixers, blowers, hot-fill (glass), cooling tunnels, labeling and secondary packing.
| PET 200 ml – 2 L | 2,000 – 16,000 bph |
|---|---|
| Focus | Viscosity, flavor and package size defined with the customer |
Dairy filling lines
Liquid milk, yogurt drink (ayran) and other microbiologically sensitive products in PET, HDPE or glass. Hygiene and bacteria-free handling from process to bottle.
| Example outputs | Turnkey dairy lines around 6,000–7,000 bph (project-specific) |
|---|---|
| Packages | PET · HDPE · glass |
Edible oil filling lines
High-efficiency PET filling, capping, labeling and packing for cooking oils. Bottle sizes and shapes are matched to the customer’s portfolio.
| PET 250 ml – 2 L | 1,200 – 12,000 bph |
|---|---|
| PET 3 L – 12 L | 300 – 1,200 bph |
| PET 5 L – 20 L | 500 – 1,000 bph |
Carbonated water and CSD lines are also in the Kombi portfolio. Capacities are indicative from kombimakina.com; each plant is engineered to the product, bottle and speed you send us.
Need a filler from Bogotá or a Kombi plant?
eFillix engineering replies from C.I. Steel. Prices and stock for eSlim models: Envasadoras.co.
